G 3038H

When you need the power to take on more demanding loads, the convenience of a hydrostatic transmission (HST), and the affordability of a basic tractor, the G3038H is your answer. With over 15% more engine horsepower and 19% more PTO horsepower than the G3033H, powers through tough soil conditions, mows down thick brush, pulls heavier loads and can take on steep inclines while reducing the need to operate at slower speeds. When combined with a powerful 1,900 lbs. of loader lift capacity, the G3038H enables you to work faster and more efficiently so you can spend more time enjoying everything you've accomplished. When you look at the power, features and value you get with the G3038H, the competition just doesn't stack up.

6_12_georgia

Modern Stylish Design

This small chassis compact 4WD is ergonomically designed and stylish with its distinctive blue color. Mechanical front wheel assist 4WD- greatly enhances traction.
7_16_ta

Mitsubishi Tier 4 Engine

The Mitsubishi Tier 4 fuel efficient engine delivers reliable performance. Rubber engine mounts reduce operator platform vibration. Easy Open One-Piece Hood - provides accessibility for easy maintenance.

Large Fuel Tank

The large 7.4 gallon capacity fuel tank provides long operation times.

PTO On/Off Switch

Turn the independent rear or mid PTO on or off with the simple and easy turn of a switch.

Hydrostatic Transmission

Maximizes ease of use with effortless, clutch-less and instant speed and directional changes with a simple push of the pedals.

Simple Selections

Select your gear range or 2WD/4WD with the simple move of the levers.

Hydrostatic Power Steering

This makes turning easier, improves control and reduces fatigue.

3-Point Hitch

Category 1 with a hitch lift capacity of 1,808 lbs. allows usage of a wide variety of implements. Drawbar Standard - increases the usefulness of the tractor without the additional optional cost.

Ergonomically Designed 3-Point Hitch Controls

Easily accessible for maximum comfort and convenience.

Adjustable Seat with Seat Belt

Keeps you in a comfortable and safe position for maximum control.

More Leg Room with Side Mounted Gear Lever

This allows for storage in low clearance buildings or sheds.

Your Choice of Tires

You can choose industrial or turf tires at no additional cost; subject to dealer inventory.

Front End Loader

Optional Quick Attach, Skid Steer Compatible Front End Loader - Remove or attach in moments. With 1,600 lbs of lift capacity it outperforms others in its class. Grill guard comes standard with loader rather than an option like others in its class.

Backhoe Attachment

Optional Quick Attach Backhoe - remove or attach in seconds. Available with 9”, 12” or 16” bucket width.

Tractor Specs

ENGINE
Manufacturer Mitsubishi
Model L3AL
Gross - Horsepower 38
Rated Engine Speed 2600
Number of Cylinders 3
Displacement-cu.in. 122.2
POWER TRAIN
Transmission Type Hydrostatic
Number Of Speeds 3 Ranges
Brakes Wet Multi Disc
HYDRAULIC SYSTEM
Pump Type Dual Gear Pump
Max Total Flow gpm 11.9
Category, 3 Point Hitch 1
Hitch Lift Capacity, lb 1808
PTO
Type Independent
Control Electric/Hydro
Mid (rpm)-Option N/A
Rear (rpm) 540
Shaft Diameter in. (mm) 1 3/8 (35)
CAPACITIES
Fuel Tank, U.S. gal 7.4
DIMENSIONS
Overall Length, in. with 3P 117.6
Overall Width, in. 41
Wheelbase, in. 65.9
Height to Top of ROPS, in. 90.2
Min. Ground Clearance, in -
STANDARD TIRES
Turf Front 25x8.5-14
Turf Rear 41x14 - 20
Ag Front 7 - 14
Ag Rear 11.2 - 24
Industrial Front 25x8.5 - 14
Industrial Rear 43x16-20
WEIGHT
Total Weight, lb 2712
